Pico Debug'n'Dump Board (Kit)

$25
0 ratings

The Pico Debug'n'Dump board is a board for interfacing with all kinds of hardware using the Raspberry Pi Pico. It will support:

- Dumping SPI-flash

- SWD debugging

- Basic glitching

- UART

- Game Boy Game-Link

- etc.

It supports target voltages from 1.6-5V, and has 8 level-shifted inputs & 8 outputs. The optional display allows you to always see the current mode and display data.

What's included:

- Debug'n'Dump board with all SMD components places (except the Raspberry Pi Pico)

- Pin-headers & socket to be soldered in (or not :) ) by the user

What's not included:

- Raspberry Pi Pico

- Optional SSD1306 display

It's inspired by boards such as the Glasgow: https://www.crowdsupply.com/1bitsquared/glasgow, the Tigard: https://github.com/tigard-tools/tigard and my own debug'n'dump board: https://twitter.com/StackSmashing/status/1192450851136249856

Once the device is fully tested & working it will be open-sourced :)


Please note that this is not a finished device, it's a board made for experimenting with the Pico with different hardware & co.

About shipping:

Shipping note: If you order two products the shop will charge shipping twice - one shipping charge will be refunded as soon as your order is dispatched. Sorry about that! (German shipping: $3.00 World-wide shipping: $6)

The shipping costs are roughly 1:1 the costs that go to the postal service. Unfortunately it is not allowed anymore to ship products in regular snail-mail, instead it has to be done via "dispatch of goods". The default shipping does not provide tracking.

Please note that because of COVID shipping to North America can have significant delays (1-2 months).

If you want tracked shipping

Gumroad does not yet provide shipping options, so if you want to have tracked shipping please buy this separately and I'll send your oder with tracked shipping: https://gum.co/trackedshipping

If you have any questions please don't hesitate to contact me: shop@stacksmashing.net
